2.54mm IDC socket 10P W/strain relief, RoHS Directive-compliant

Model No.
YRF10
Made in
Taiwan
Request for Quotation


Network with over 300 Taiwan quality suppliers! More than 20,000 items to choose from!

Spec

  • Cable Type:Others

Key Features

  • IDC socket 10P W/strain relief
  • RoHS Directive-compliant
  • Specifications:
    • Pitch: 2.54mm
    • Current rating: 3A
    • Voltage rating: 250VAC
    • Contact resistance: 20mΩ Max. at 1A DC
    • Insulation resistance: 5000MΩ Min. at 500VDC
    • Dielectric withstanding voltage: 500VAC for 1 minute
  • Materials:
    • Insulator: Glass-filled thermoplastic PBT, UL94V-0 rated
    • Contact: Copper alloy
  • Other header connector items are available, refer to the attached PDF file

※More detailed specification, competitive prices and flexible quantities, please check and buy on our web-site www.shallin.com.tw!

Product Certification

Payment Details

  • Payment Terms:TT ,PayPal
  • Minimum Order:180 Piece(s)
