RF/Coaxial connector, BNC male crimp type (RG58U) gold-pin, RoHS Directive-compliant

Model No.
M5569L
Made in
Taiwan
Request for Quotation


Network with over 300 Taiwan quality suppliers! More than 20,000 items to choose from!

Key Features

  • Impedance: 50Ω/75Ω
  • Frequency range: 0 to 4GHz/0 to 1GHz
  • Voltage rate: 500V AC
  • Contact resistance: 3.0mΩ max
  • Insulation resistance: 5000MΩ min at 500V DC
  • Withstanding voltage: 1500V AC in one minute
  • RG8AU, RG58U, RG59U, H155, RG174U, RG223U are all available
  • Insulation Bakelite or Teflon are available
  • Other BNC connectors are available, please see the attached catalogues
※ More detailed specification, competitive prices and flexible quantities, please check and buy on our web-site www.shallin.com.tw!

Product Certification

Payment Details

  • Payment Terms:TT ,PayPal
  • Minimum Order:100 Piece(s)
