2.5mm DC power jack, RoHS Directive-compliant

Model No.
K36721B
Made in
Taiwan
Request for Quotation


Network with over 300 Taiwan quality suppliers! More than 20,000 items to choose from!

Key Features

  • 2.5mm DC power jack
  • RoHS Directive-compliant
  • Rating: 30VDC 0.3A, (16V 2A)
  • Contact resistance: 5VDC/1A, 100mΩ
  • Insulation resistance: 500VDC, 100MΩ
  • Withstand voltage: 500VAC, 1 minute
  • Connection force: 0.3-3Kgf
  • Disconnection force: 0.3-1.5Kgf
  • Life cycle: 5000 cycles Max.
  • Other DC power jacks are available, see the attached catalogue
※More detailed specification, competitive prices and flexible quantities, please check and buy on our web-site www.shallin.com.tw!


Product Certification

Payment Details

  • Payment Terms:TT ,PayPal
  • Minimum Order:500 Piece(s)
